Description:
LENS UP FOR BETTER VISION
Specification:
Chip Model
|
1 / 3" 200W CMOS
|
Processor
|
XC5322
|
Viewing Angle
|
Horizontal 200±5°, Vertical 120±5°
|
Lens Model
|
6048
|
Video Signal
|
AHD
|
Sensor Pixel
|
1280(H) × 720(V), Supports 720P
1920(H) × 1080(V), Supports 1080P
|
Frame Rate
|
25 fps
|
Video Output
|
1.0 Vp-p, 75Ω
|
Minimum Illumination
|
0.001 LUX
|
Backlight Compensation
|
Auto |
Gain Control
|
Auto |
| White Balance |
Auto |
Signal-To-Noise Ratio
|
≥58dB
|
Dynamic Range
|
80dB
|
Waterproof Class
|
IP68
|
Power Supply
|
3.4 - 5V DC
|
Working Current
|
100 ± 10mA
|
| Operation Temperature |
-25℃ ~ 70℃
|
| Storage Temperature |
-30°C ~ 80℃ |
